ALLSCREEN electric projector lift CEL1500
Weight: 22
SKU: CEL1500
Description
Tubular motor - Adopt silent tubular motor,silent and big power,load of weight can reach 15KGS;
Wireless remote control - Equipped with RF or IR remote control,easy to control its up and down;
Mechanical limit - Adopt mechanical limit,positioning accuracy and fault-free ;
solid and durable - Double scissors and belts,solid and durable;
OEM & ODM - Accept OEM and ODM,different running distance is optional;
| Model | CEL1000 | CEL1500 | CEL2000 |
| Size: | 350mm*300mm*200mm | 350mm*300mm*240mm | 350mm*300mm*280mm |
|
Thickness(BOX and SCISSORS): |
200mm | 240mm | 280mm |
| Size of decorative board: |
480mm*480mm /500mm*500mm /600mm*600mm |
480mm*480mm /500mm*500mm /600mm*600mm |
480mm*480mm /500mm*500mm /600mm*600mm |
| Size of hole position on fixed board: | 200mmx230mm | 200mmx230mm | 200mmx230mm |
| Maximum running distance: | 1000mm | 1500mm | 2000mm |
| Controller: | RF remote control(Rs232 or Rs485 is optional) | RF remote control(Rs232 or Rs485 is optional) | RF remote control(Rs232 or Rs485 is optional) |
| Motor: | Tubular motor | Tubular motor | Tubular motor |
| Load(kg) | 15KG | 15KG | 15KG |
| Rated voltage(V) | customization | customization | customization |
| Package size: | 570mm*570mm*325mm | 570mm*570mm*375mm | 570mm*570mm*435mm |
| Net weight: | 18KG | 20KG | 23.5KG |
| Gross weight: | 19.8KG | 22KG | 25KG |
