ALLSCREEN Q SERIES INTERACTIVE FLAT PANEL 85 INCH 4K ANDROID 9.0 DW85HQ560 20 TOUCH POINT SMART BOARD
Weight: 107
SKU: DW85HQ560
Description
| Display Parameter | Diagonal Size | 85inch | |
| Effective Display Area | 1872(H)×1053(V) | ||
| Display Ratio | 16:9 | ||
| Brightness | 350cd/㎡ | ||
| Contrast Ratio | 4000:1 | ||
| Backlight Type | DLED | ||
| Viewing Angle | 178°(V)/178°(H) | ||
| Resolution | 3840（H) X 2160(V) | ||
| Audio Output Power | 8Ω/15W*2 | ||
| Back port | Input | USB 2.0 | 2 |
| RJ45 | 1 | ||
| HDMI 2.0 | 2 | ||
| Mic | 1 | ||
| VGA | 1 | ||
| VGA Audio | 1 | ||
| RS232 | 1 | ||
| OUT | USB TOUCH | 1 | |
| coaxial(RCA) | 1 | ||
| Earphone | 1 | ||
| Front port | USB2.0（Android & Windows USB3.0） | 2 | |
| HDMI 2.0 | 1 | ||
| USB TOUCH | 1 | ||
| Front button | Power Button | ||
| PC | PC Option | H81 Mainboard | |
| Android Specs | Android Frequency | Quad-core A55 1.5GHz | |
| System Version | Android 9.0 | ||
| Memory | DDR4 3G | ||
| FLASH | 32G | ||
| 2.4GWIFI | Wifi*2 | ||
| 5GWIFI | Wifi*2 | ||
| Others | Power consumption | ≤350W | |
| Standby consumption | ≤0.5W | ||
| Lifetime | 50000 hours | ||
| power supply | 100-240V, 50/60Hz | ||
| Demission | 1962.8*1194.1*100.3mm | ||
| Net Weight | 90kg | ||
| Gross Weight | 107kg | ||
| package size | 2095*1320*230mm | ||
| Touch screen | Touch technology | Multiple Infrared scanning technology | |
| Touch type | 20 point touch | ||
| Drive Mode | HID Free drive | ||
| Writing surface material | 5 mm anti glare tempered glass | ||
| Touch Screen Sensor Mode | Finger, writing pen, hand with gloves or other non transparent touch sensitive medium | ||
| Resolution of touch screen | 32767X32767 | ||
| Communication Port | USB 2.0 | ||
| Minimum Recognition Point Size | 2.5mm | ||
| ResponseTime (SingleTouch) | ≤8ms | ||
| Touch Accuracy | ±1mm | ||
| Anti-Interference | Incandescent lamp (220V, 100W), vertical distance 350mm above, The illumination intensity of the sun is up to 90000Lux | ||
| Calibration | Calibration free | ||
| Touch Time | More than 60 million times in the same position | ||
| Touch Power supply Mode | USB 5.0V power supply | ||
| Accessories | Wall-Mount | 1pcs | |
| Pen | 2pcs | ||
| Manual | 1pcs | ||
| power cable | 1pcs | ||
| Remote control | 1pcs | ||
